LT-1988 Mobile Radio

Function:

TECHNICAL CHARACTERISTICS

General
Frequency Range	66-88 MHz, 136-174 MHz or 400-470 MHz
Number of Channels	199 channels
Channel Spacing	25KHz(Wide Band);
Channel Spacing	12.5kHz(Narrow Band)
Phase-locked Step	2.5K,5K,6.25K,10K,12.5K,20K,25K,30K,50K
Operating Voltage	13.8V DC ±15%
Squelch	Carrier/CTCSS/DCS
Frequency Stability	±2.5ppm
Dimensions	109 (W) x 104(D) x 25 (H)mm
Weight	about 0.5Kg
Operating Temperature	-20℃ to +60℃
Receiver
	Wide band	Narrow band
Sensitivity (12dB SINAD)	≤0.25μV	≤0.35μV
Adjacent Channel Selectivity	≥60dB	≥60dB
Intermodulation	≥60dB	≥60dB
Spurious Rejection	≥60dB	≥60dB
Audio Response	+1~-3dB(0.3~3KHz)	+1~-3dB(0.3~3KHz)
Hum & Noise	≥45dB	≥40dB
Audio distortion	≤5%
Audio power output	>2W@16R
Transmitter
	Wide band	Narrow band
Power Output	15W / 10W / 5W
Modulation	16KΦF3E	11KΦF3E
Adjacent Channel Power	≥70dB	≥60dB
Hum & Noise	≥40dB	≥36dB
Spurious Emission	≥60dB	≥60dB
Audio Response	+1~-3dB(0.3~3KHz)	+1~-3dB(0.3~2.55KHz)
Audio Distortion	≤5%
