Product Description
Product Description
Main features:
Great structure design, anti-wrestling;
7Watts power output;
Flash torch;
12.5KHz/25KHz channel spacing selectable;
High/Low Power Switchable;
Monitor ;
Auto Battery Save ;
Low Battery Alert;
Busy Channel Lockout;
VOX;
CTCSS-50/CDCSS-105, standard & nonstandard CTCSS codes available;
TOT (Time-out timer);
ending sound silence;
squelch level 0-9 adjustable;
Priority Channel Scan ;
Different Frequency Function;
PC Programmable;General:
Frequency Range:VHF 136-174MHz 245-246MHz UHF400-480MHz 350-390MHz 465-520MHz
Channel No.: 2×128
Channel Spacing : 12.5/25KHz
Voltage : 7.2V
Battery : 1800mAh(Li-Ion)
Frequency Stabilization : ±2.5ppm
Operating Temperature Range : -20°C~+55°C
Antenna Impedance : 50Ω
Distances : 2~15km
Transmitter :
RF Power Output : 7W
Modulation Type : F3E
Spurious and Harmonic: ≤ -60dB
Residual Radiation : ≤ -40dB
Modulation Distortion: ≤5%
Maximum Frequency Deviation : ±5KHz
Receiver :
Sensitivity : ≤0.2µV
Modulation Band: ±5KHz
Adjacent Channel Selectivity : ≥60dB
Inter-modulation Anti-interference : ≥60dB
Spurious Response Rejection: ≥60dB
Rated Audio Output Power : ≥500mW
Rated Audio Distortion : ≤5%
Package Include:
1x Radio
1x Battery Pack
1x Power Adapter
1x Antenna
1x Belt Clip
1x Wrist Strap
1x User Manual
