Product Description
https://youtube.com/watch?v=%25E2%2580%259CFlsUW-y0rnc%25E2%2580%259Dalign%3Fhtml5%3D1
LUITON LT-188H VHF Long Range Radio has been chosen as one of the best Long Range Two Way Radios by GeekWrapped – Online product & gift suggestion platform.https://www.geekwrapped.com/outdoors/best-long-range-two-way-radios
lt-188H 10w handheld long range transceicer
Main features:
Great structure design, anti-wrestling;
10Watts power output;
Flash torch;
12.5KHz/25KHz channel spacing selectable;
High/Low Power Switchable;
Monitor ;
Auto Battery Save ;
Low Battery Alert;
Busy Channel Lockout;
VOX;
CTCSS-50/CDCSS-105, standard & nonstandard CTCSS codes available;
TOT (Time-out timer);
ending sound silence;
squelch level 0-9 adjustable;
Priority Channel Scan ;
Different Frequency Function;
PC Programmable;
| General | |
| Frequency Range | 136-174MHz，400-470MHZ，450-520MHz |
| Channel No. | 16 |
| Channel Spacing | 12.5 / 25KHz的 |
| Voltage | 7.5V |
| Battery | 2800mAh（Li-Ion） |
| Frequency Stabilization | ±2.5ppm |
| Operating Temperature Range | -20℃〜+ 55℃ |
| Antenna Impedance | 50Ω |
| Size（H * W * d） | mm（H）×mm（W）×mm（D） |
| Weight（Including antenna, battery） | 280g |
| Distances | 2〜15km |
| Transmitter | |
| RF Power Output | 10W |
| Modulation Type | F3E |
| Spuirous and Harmonic | ≤-60dB |
| Residual Radiation | ≤-40dB |
| Modulation Distortion | ≤5％ |
| Maximum Frequency Deviation | ±5KHz |
| Receiver | |
| Sensitivity | ≤0.2μV |
| Modulatioin Band | ±5KHz |
| Adjacent Channel Selectivity | ≥60dB |
| Inter-modulation Anti-interference | ≥60dB |
| Spurious Response Rejection | ≥60dB |
| Rated Audio Output Power | ≥500mW |
| Rated Audio Distortion | ≤5％ |
Package Include:
1x Radio
1x Battery Pack
1x Power Adapter
1x Antenna
1x Belt Clip
1x Wrist Strap
1x User Manual
1x Programming Cable
1x Software CD
