Product Description
Latest LUITON LT-868 hf transceiver from china
Features:
Frequency: 156-162MHz for marine, 136-174MHz, 400-470MHz
- 25W RF output
- CTCSS (50 tones)
- DTMF codes
- Backlight
- Auto-scan function
- MR memory function
- VFO program (input the frequency you want by keypad)
Latest LUITON LT-868 hf transceiver from china
Specification:
| Number of Channel 128 programmable channels |
| CTCSS 50 group CTCSS transmit (inner) |
| 50 group receive (options) |
| Channel Spacing 5,10,12.5,25KHz |
| Modulation FM |
| Mode of Operation Simplex or Semi-duplex |
| Antenna Impedance 50Ω |
| Operating Voltage 13.8V |
| Mode of ground wire cathode ground wire |
| Operating Temperature -10°C~+55°C |
| Output power L:5W H: 30W |
| Spurious and image rejection ≤-60dB |
| Current Consumption ≤8A (when transmit@30W) |
| Maximum Deviation ≤±4.5 KHz |
| Sensitivity Adjustment 2~20mV |
| Frequency Stability ±5ppm |
| Usable Sensitivity 0.18µV (12dB SINAD) |
| Squelch Sensitivity Threshold ≤0.2µV |
| Tight Squelch Sensitivity ≤3µV |
| Audio Output ≥3W |
| Audio Distortion ≤10% |
| Audio Frequency Response 300~3000Hz |
