LT-725UV dual band mobile radio

    Function:

    • Dual band: 136-174MHz/400-480MHz/
    • Dual Reception/Dual Display
    • Voice Compand and Scrambler
    • DTMF encoding and DTMF decoding
    • PTT ID(Voice broadcast PTT ID)
    • All calls, group calls and selective calls
    • Monitor, RX Inhibit, RXTX Inhibit and Emergency Alarm
    • FM Radio(87.5MHz-108MHz)
    • Scan/Scan add

    Product Description

    LT-725UV dual band mobile radio

    Features of  LT-725UV dual band mobile radio :

    Please note: The model LT-725UV is the mini size mobile radio ,with high power output up to 25 watts ,with a big fan at the backside ,High-Middle-Low power output ,H<25W M<10W, L<5W ,and with the Car cigarette power cable .

    Main features:
    1. Dual band: 136-174MHz/400-480MHz;
    2. Dual Reception/Dual Display ;
    3. Voice Compand and Scrambler;
    4. Multi silent mode (QT/QTADT/QTXDT) 107 groups DCS/58 groups CTCSS;
    5. DTMF encoding and DTMF decoding;
    6. PTT ID(Voice broadcast PTT ID);
    7. All calls, group calls and selective calls;
    8. Monitor, RX Inhibit, RXTX Inhibit and Emergency Alarm;
    9. FM Radio(87.5MHz-108MHz);
    10. Scan/Scan add;
    11. Channel name edit available;
    12. 128 memory channels;
    13. High/Middle/Low power

    14. TOT (Time-out timer);
    15. Busy channel lockout;
    16. Channel steps (2.5K/5K/6.25K/10K/12.5K/25K/50K);
    17. Wide/Narrow band selection (25KHz/12.5KHz);
    18. Reverse frequency function;
    19. Four key programmable;
    20. Input frequency by using Keypad ;
    General:
    Band: VHF&UHF Dual Band
    Frequency Range: 400-480MHz &136-174MHz
    Channel Capacity: 128 Channels
    Output Power: 25W/10W/5W
    Operation Mode: Simplex
    Modulation Limitation: ≤±5KHz
    Frequency Stability: <0.18µV
    Modulation Type: F3E
    Rated Voltage: 13.8V
    Package Include:
    1x Radio
    1x Keypad Microphone
    1x Car Cigarette Power Cable
    1x Bracket
    1x Bracket Screw
    1x User Manual
    1x Programming Cable
    1x Programming Software CD

    Technical Specifications of  LT-898UV dual band mobile radio

    BandLT-725UV dual band mobile radio
    Frequency Range400-480MHz &136-174MHz
    Channel Capacity128 Channels
    Output Power5W/10W/25W
    Operation ModeSimplex
    Dimension(L*W*H)105 * 30* 106mm
    Weight500g
    Modulation Limitation≤±5KHz
    Spurious Radiation60dB
    TX Current1A/1.8A
    Frequency Stability<0.18µV
    Modulation TypeF3E
    Max.Audio output2W @8Ω 5% distortion
    Rated Voltage13.8V

    LT-725UV dual band mobile radio
