Product Description

LT-580 UHF Mobile Radio

Frequency Range:
VHF: 136-174MHz/245-245.9875MHz (220-260MHz)
UHF: 400-490MHz/450-520MHz
Output Power:
VHF: 60W/25W
UHF: 45W/25W
Large screen lcd display
adjustable brightness, easy to use at night
operation Optional
200 Programmable Memory Channels
Easy to operate , better heat-release
Each channel can be set to different CTCSS / DCS, 2Tone, 5TONE signal,
Reject unwanted calls from other stations
Multiple scanning function, CTCSS/DCS setting & scanning
By using 5Tone to finish data transmission,emergency alert,
all call, ANI identification, Remote kill ,Remote awake;
DTMF-ANI or 5Tone-ANI Caller automatic recognition
Scrambler (Optional)
You can set different band in each channel, Wide band 25K/Narrow band 12.5K
Voice Compander

General
Frequenvy Range	VHF:136-174MHz/ 245-245.9875MHz (220~260MHz)UHF:400-490MHz
Number of Channels	200Channels
Channel Capacity	25K(Wide Band)/20K(Middle Band)/12.5K(Narrow Band)
Channel Spacing	5/ 6.25/ 8.33/ 10/ 12.5/ 15/ 20/ 25/ 30/ 50KHz
Freruency Stability	±2.5ppm
Operating Temperature	-20℃ ~ + 60℃
Squelch	Carrier/ CTCSS/ DCS/ 5Tone/ 2Tone/ DTMF
Operating Voltage	13.8V DC ± 15%
Dimension(HxWxD)	145mm x190mm x47mm
Weight(with bracket)	1200g
Receiver (ETSI EN 300 086 standard testing)
	Wide band	Narrow band
Sensitivity (12dB Sinad)	≤0.25µV	≤0.35µV
Operating Bandwidth	≥70dB	≥60dB
Adjacent Channel Selectivity	≥70dB	≥60dB
Inter-modulation Rejection	≥65dB	≥60dB
Spurious Response Rejection	≥70dB	≥70dB
Rated Audio Response	+1-+3dB(0.3~3Khz)	+1-+3dB(0.3~2.55Khz)
Hum & Noise	≥45db	≥40db
Rated Audio Distortion	<5%
Audio Powe Output	>2W@10%
Transmitter (ETSI EN 300 086 standard testing)
	Wide band	Narrow band
RF Power	60W/25W(VHF)	45W/25W(UHF)
Modulation	16kΦF3E	11kΦF3E
Hum & Noise	≥40dB	≥36dB
Adjacent Channel Power	≥70dB	≥60dB
Spurious Emission	≥60dB	≥60dB
Audio Response	+1-+3dB(0.3~3Khz)	+1-+3dB(0.3~2.55Khz)
Audio Distortion	<5%
