Product Description
Features:
CE Approved
136~174MHz & 400~470MHz dual band professional two way radio, 96 channels
The three- dimension protective structure makes the battery connecting more tighten
Meets IP67 standards waterproof structure
Connection any structure to 1+1 smart chargers
Dual band, 96 channels
Meets IP67 standards waterproof structure
1+1 smart chargers
Three- dimension protective structure
Emergency Alarm Function (TOT (Time-out timer))
High/Low Power Switchable (PC Programmable)
Wide Channel spacing: 12.5K /25K (Monitor)
Auto Battery Save ( CTCSS-50/CDCSS-105)
VOX (Ending sound silence)
Low Battery Alert (Squelch level 0-9 adjustable)
Busy Channel Lockout ( Channel Scan)
Wire Cloning
CE Dual band LT-558UV vertex two way radio battery
Specification:
| General | |
| Frequency Range | VHF:136-174MHzUHF:400-470MHz |
| Channel No. | 96Channel |
| Channel Spacing | 12.5/25KHz |
| Voltage | 7.5V |
| Battery | 1600mAh(Li-Ion) |
| Frequency Stabilization | ±2.5ppm |
| Operating Temperature Range | -20°C~+55°C |
| Antenna Impedance | 50 |
| Dimensions(H*W*D) | 119mm(H)× 53mm(W)× 32 mm(D) |
| Weight(including antenna, battery) | 210g |
| Transmitter | |
| RF Power Output | 5W |
| Modulation Type | F3E |
| Spuirous and Harmonic | ≤ -60dB |
| Residual Radiation | ≤ -40dB |
| Modulation Distortion | ≤5% |
| Maximum Frequency Deviation | ±5KHz |
| Receiver | |
| Sensitivity | ≤0.2µV |
| Modulatioin Band | ±5KHz |
| Adjacent Channel Selectivity | ≥70dB |
| Intermodulation Anti-interference | ≥65dB |
| Spurious Response Rejection | ≥70dB |
| Rated Audio Output Power | ≥500mW |
| Rated Audio Distortion | ≤5% |
