LT-308 LCD display 40 channels am/fm 27mhz cb radio |LUITON

LT-308 LCD display 40 channels am/fm 27mhz cb radio

• Frequency: 25.615~30.105MHz

• 4Watts or 10Watts CB radio

• Channels: E D EU EC PL UK US NZ

• Expand Mode Freq: RU PO PC

• Emergency call channel available (CH9).

• SQ function.

• ASQ function.

Technical Specifications :

General
Modulation modes	AM/FM
Frequency range	26.965-27.405MHz
Antenna impedance	50 Ohms
Power supply	13.2V
Dimensions	115(L)×38(A)×150(P)mm
Weight	0.8kg
Transmission
Frequency error	+/-300HZ
Carrier power	1W/4W
Transmission interference	Inferior to 4nW(-54dBm)
Audio response	300HZ to 3KHZ in AM/FM
Emitted power in the adj. channel	inferior to 20uW
Microphone sensitivity	3mV
Maximum current	max 3A
Modulated single distortion	inferior ro 5%
Reception
Max sensitivity at 20dB sinad	0.8μV-113 dBm FM
	1.5μV-103 dBm AM
Frequency response	300HZ to 3KHZ in AM/FM
Adjacent channel selectivity	60dB
Maximum audio power	3W
Squelch sensitivity	Minimum 0.2μV -120dBm
	Minimum 1mV -47dBm
Maximum current	0.3A nominal/1.2A maximum

packing including:

LT-308 LCD display 40 channels am/fm 27mhz cb radio
