Specifications
LT-168 CB Radio
40 Channels
Frequency 25.615-28.305MHz
Warranty; 1 year
Delivery time: 30days after T/T
LT-168 CB Radio
Feature:
AM/FM Mode For Selection
ANL-OFF Selector
Signal Strength Indication.
Squelch control
AM/FM Mode For Selection
Signal Strength Indication.
Full 4 Watts RF power
RF Gain Control
ANL-OFF Selector
LOC-DX Selector
ASQ Function
Emergency Channel 9/19
Squelch Control
Scan Function(automatic search of busy channels)
Memory channel(M1-M4) Selection
PA Function
LED back-light
No License Required.
Technical Specification
| General | |
| Frequency Range | VHF:25.615-28.305MHz |
| Frequency control | P.L.L |
| Channels | 40AM/FM |
| Power supply | 13.8Vdc±15% |
| Operating temperature | -10°C~+55°C |
| Weight | About 1.3kg |
| Size | 160 (W)×140(D)×44mm (H) |
| Transmitter | |
| RF power output | 4W(at 13.8Vdc) |
| Carrier freq. error | <±800Hz |
| Modulation | 60% to 70% @ 8mV 1 kHz audio tone input (AM) 80% to 90% @20mV 1 kHz audio tone input (AM) 1.5 KHz @8 mV 1 kHz audio tone input (FM) 2 KHz Hz @50 mV 1 kHz audio tone input (FM) |
| Spurious emissions | 60dBc(typical) |
| Receiver | |
| Reference sensitivity | -118dBm @ 12dB SINAD (FM)-107dBm @ 12dB SINAD (AM) |
| Current consumption | 180mA(stand-by) |
| System | Double conversion with CPU controlled |
| Audio output | 2.5w at 10% THD,16ohm loading |
